APC Basic 0U Vertical Rack PDU, 15A 100/120V Power Distribution Unit with (14) NEMA 5-15 Outlets, AP9567
| Series | APC 9000 Series | Rack Units | 0U |
| Length | 3.6 m | Color | Black |
| Mount Direction | Vertical | Rating | 15A/120V |
| UL Listed | Yes | RoHS Compliant | Yes |
| Equipment End | NEMA 5-15P | PDU Type | Basic |
| Ac Input Voltage | 100V to 120V | Brand | APC |
| Line Rated Current | 12A | Mounting Location | Side |
| USB Compatible | No | Communication Port Protocol | SNMP, Redfish |
| Outlet Configuration | (14) Nema 5-15 |
AP9567 | Power Distribution Units | APC Basic 0U Vertical Rack PDU, 15A 100/120V Power Distribution Unit with (14) NEMA 5-15 Outlets | NIB
The APC AP9567 Basic 0U Vertical Rack PDU provides reliable 100/120V, 15A power distribution for servers, switches, and rack-mounted equipment. Featuring 14 NEMA 5-15R outlets and a NEMA 5-15P input, this space-saving PDU mounts vertically without using rack units. Its tool-less installation, durable construction, and built-in overload protection make it an ideal solution for data centers, network closets, and IT enclosures.
Features:
- Built-in load monitoring — view real-time current draw to plan capacity and avoid overloads.
- Outlet sequencing / delayed start — control power-up order to protect sensitive equipment
- Network management support with secure access (Web/UI, SNMP, Telnet/SSH depending on firmware)
- Secure management protocols (e.g., TLS encryption) for safe remote access
- Zero-U vertical form factor saves valuable rack space
- Enables remote troubleshooting and control, reducing need for physical onsite access
- Ideal for managed infrastructure, colocation, and distributed IT environments
- Remote power cycling and rebooting for connected equipment
- Nominal Input Voltage: 100 V / 120 V AC
- Nominal Output Voltage: 100 V / 120 V AC
- Input Frequency: 50 Hz / 60 Hz
- Maximum Total Current Draw: 15 A
- Regulatory Derated Input Current (North America): 12 A
- Load Capacity: ~1400 VA (North America)
- Output Connections: (14) NEMA 5-15R outlets
- Input Connection: NEMA 5-15P plug (attached power cord)
- Overload Protection: Yes (built-in circuit protection)
- Operating Temperature: 32 °F to 113 °F (0 °C to 45 °C)
- Operating Humidity: 0 % – 95 % non-condensing
- Operating Elevation: 0 – 10,000 ft (0 – 3048 m)
- Storage Temperature: –25 °C to 65 °C
- Storage Humidity: 0 % – 95 %
- Storage Elevation: 0 – 50,000 ft (0 – 15240 m)
- APC AP9567 PDU
- Cord retention bracket(s) (to secure the power cord in place)
- Rack mounting brackets
- Installation guide with instructions for setup and mounting
- User manual / safety guide with operating details and safety information
